Electrical Specifications
Performance Property Units US (metric) |
||||
Velocity of Propagation % | 82 | |||
Dielectric Constant | NA | 1.38 | ||
Time Delay | nS/ft (nS/m) | 1.20 | (3.92) | |
Impedance | ohms | 50 | ||
Capacitance | pF/ft (pF/m) | 23.9 | (78.4) | |
Inductance | uH/ft (uH/m) | 0.060 | (0.20) | |
Shielding Effectiveness | dB | >90 | ||
DC Resistance | ||||
Inner Conductor Outer Conductor
Voltage Withstand |
ohms/1000ft (/km) ohms/1000ft (/km)
Volts DC |
2.12
2.21 |
2000 |
(7.0)
(7.3) |
Jacket Spark | Volts RMS | 5000 | ||
Peak Power | kW | 10 |
