TECHNICAL CHARACTERISTICS | |
Digital gain display | LED digital display shows current amplifier gain. |
Touch-tone gain adjustment | upper and lower key, we can adjust the gain. |
Power control | Toggle the power switch, easy control power supply state. |
Serial command control | |
GNSS re-radiator device will support for below frequencies | |
GPS | L1 / L2 / L5 |
GLONASS | L1 / L2 / L3L1 / L2 / L3 |
BeiDou | B1 / B2 / B3 |
QZSS | L1 / L2 / L5 |
Galileo | E1 / E1a / E5a / E5b / E6 |
IRNSS | L5,SBAS |
The device features 0-30dB gain and a noise figure less than 3dB. | |
LMR 240 Cable used to connect Passive antenna up to 40 meter. | |
LMR 400 Cable used to connect From Roof Top antenna to Device maximum 120 meter. |
VSW-GNSS-RR — GNSS Re-Radiator
Application
- Mobile Phone Testing Vehicle
- Tracking Testing GPS Hand
- Held Testing Car navigators
- Testing Military Equipment
- Testing@ indoors Dashboard
- Testing Survey product Aviation
- Hanger Public Transportation
