SS402 Precision Coax Cable, N Male Straight / N Male Straight
SS402 Precision Coax Cable, N Male Straight / N Male Straight
PART NO:-VSW-NM-NM-SS402
Description
| SPECIFICATION | |
| RF Series 1 | N |
| Gender | Plug (male) |
| Coupling | Threaded |
| Orientation1 (body) | Straight |
| Termination style | Crimp |
| RF Series 2 | N |
| Orientation 2 (body) | Straight |
| Gender 2 | Plug (male) |
| Impedance | 50 Ohms |
| Frequency | 18 GHz |
| Insertion Loss | 0.66 dB/ft. Type at 18 GHz |
| VSWR | <1.3, DC to 18 GHz |
| Nominal Capacitance | 29 pF/ft. |
| Velocity of Propagation | 70% |
| Shield Effectiveness | Greater than 110 dB |
| Length | 24” |
| Connector Corrosion (salt spray) | MIL-STD-202, method 101, test cond. B 5% salt solution. |
| Connector Durability: | 500 connections Minimum |
| Jacket Colour | Blue |
| Operating Temperature | -45°C to +85°C |
