VSW-1W-18G1-SMA — 1W RF TERMINATION LOAD (DC-18GHZ, SMA MALE)
- RF Passive Device
- RF Termination Load
- DC-18GHz
- SMA Female
Description
| SPECIFICATION | |
| Body Finish | Gold |
| Body Material | Brass |
| Contact Finish | Gold |
| Contact Material | Brass |
| Gender | Jack(Female) |
| Impedance (Ohms) | 50 |
| Orientation | Straight |
| Power Handling | 1watt @25°C |
| Mating Cycles | ≥100 |
| Return Loss | ≥20 dB |
| Frequency | DC-18GHz |
| Temp (Max Degrees Celsius) | +85°C |
| Temp (Min Degrees Celsius) | -40°C |
